4 Side Sealing Packaging Machine

Dustial Machinery® 4 Side Sealing Packaging Machine Feature

• Stainless steel frame
• Servo-driven film transporting.
• Servo-driven end seal jaws operating
• PLC controller with touch screen interface
• Hot printer and film feeding system synchronous
• Quickly changing one-piece bag former
• Eye mark sensor for film tracking

Dustial Machinery® 4 Side Sealing Packaging Machine Application

• Powder: Pesticide powder, seasoning, pearl powder, chemistry sample etc.
• Granule: Seeds, dry fruit, medicament, hardware etc.
• Liquid: wine, vinegar, detergent, medicament etc.

Optional device

• Nitrogen gas flushing
• Hole punch device
• Safety device
• Static eliminator
• Film tracking device
• Special sealing jaws
• Thermal transfer printer

Packing material

Heat sealable roll film
• Laminated film
• Various complex films

Model	BY-480	BY-560
Film width	220-480mm	260-560mm
Bag length	50-300mm	50-380mm
Speed	Max. 50 bpm	Max. 50 bpm
Power supply	220V, 50/60HZ, 3.5Kw	220V, 50/60HZ, 4Kw
Air requests	0.35m3/min, 0.6Mpa	0.4m3/min, 0.6MPa
Outer dimension	1680x1150x1510mm	1710x1220x1700mm
